Description
key Features
· Balanced handle for comfortable & firm grip
· Easy trigger action for convenient use
Specification
Cup capacity (litres) : 0.57
Gun distance from work piece mm(inch) : 228.6 (9)
Fluid nozzle orifice dia. (mm) : 1.6
Required pressure (kgs/sq.cm) : 2.8-4.2
Air consumption of rated pressure lit/min(c.f.m) : 225-300(8-10)
Material output (cc/min) : 325
Max. pattern width (mm) : 250
Min. Air-compressor (HP) : 1-2
Weight of gun with cup (gms) : 753
